General Specifications
- Type
- 3-way In-Wall/In-Ceiling loudspeaker
- Low Frequency Driver
- 8-inch (203mm) woofer with 1.5-inch (38mm) voice coil
- Mid Frequency Driver
- 1.18-inch (30mm) voice coil transducer with neodymium magnet
- High Frequency Driver
- 1-inch (25mm) voice coil transducer with neodymium magnet
- Recommended Amplifier Power
- 50 – 160 WRMS
- Impedance
- 4 Ohm
- Loudspeaker Sensitivity
- 84 dB/1W/1m measured in-room
- Frequency Response
- 45 Hz – 20 kHz (-6 dB) measured in-room
- Crossover Frequency
- 500 Hz
- Enclosure Type
- Sealed, with wooden back-box
- Protection
- Two independent self-resetting devices (LF and MF/HF)
- Input Type
- Five-way gold-plated spring-loaded binding posts
- Warranty
- 5 Years
Dimensions
- Panel Dimensions
- 22 H x 15-7/8 W x 3-7/8 D (559mm H x 403mm W x 98mm D)
- Cut-out Dimensions
- 22-1/8” H x 16” W (562mm H x 406mm W)
- Mounting Depth
- 3-3/8-inches (86mm)
- Product Weight
- 21.8 lbs (9.9kg)
- Shipping Weight
- 25.5 lbs (11.5kg)
