General Specifications
- Enclosure Type
- Bass-reflex design with rear-firing port
- High Frequency Transducer
- 1-inch (25mm) Teonex compression driver
- Low / Mid Frequency Transducers
- Three 8-inch (200mm) black Advanced Aluminum Matrix cone, cast frame woofers
- Crossover Frequency
- 800Hz, 1800Hz
- Sensitivity (2.83V @ 1M)
- 92dB
- Nominal Impedance
- 4 Ohm
- Recommended Amplifier Power
- 25W – 300W
- Frequency Response
- 37Hz – 30kHz (-6dB)
- Dimensions (H x W x D)
- 43.33 x 11.81 x 16.45” (1100.5 x 300.0 x 417.8mm)
- Net Weight
- 83.78 lbs (38.00kg)
