JBL 8124

General Specifications

Component

4 in (100 mm), full-range driver

Frequency Range

60 Hz – 18 kHz

Sensitivity

93 dB (1 kHz – 8 kHz), 1W, 1M

Coverage

130° conical

70V/100V Taps

6W, 3W, 1.5W (0.75W at 70V only)

Termination

Bare wires

Nominal Driver Impedance

8 ohms

Driver Power Capacity

20 W

Plenum Usage

Not intended for use in return air plenums

Included Accessories

Sculpted Grille

Optional Accessories

MTC-8124C C-ring, MTC- Rail tile rails

Dimensions

Diameter

8.1 in (206 mm)

Depth

3.5 in (89 mm)

Weight

2.5 lb (1.2 kg)

Cutout Dimension

175 mm diameter (6.9 in)
