General Specifications
- Frequency Range (-10dB)
- 80 Hz – 20 kHz
- Frequency Response (±3 dB)
- 100 Hz – 20 kHz
- Coverage Pattern
- 120° x 120°
- Directivity Factor (Q)
- 8.1 (1 k – 16 kHz)
- Directivity Index (DI)
- 8.4 dB (1k – 16 kHz)
- System Power Rating
- 250 W 2 hrs. 200 W 100 hrs
- Sensitivity (2.83V @ 1m)
- 94 dB (Ave. 100 Hz – 20 kHz)
- Maximum SPL (1m)
- Direct 8Ω = 118 dB (peaks of 124 dB) 200 W Tap = 117 dB
- Crossover Network
- 1.8 kHz, 3rd order (18 dB/oct) high-pass plus conjugate to HF, 2nd order low-pass to LF
- Nominal Impedance
- 8 ohms
- Transformer Taps
- 70V = 200W, 100W, 50W, 25W ; 100V = 200W, 100W, 50W
- LF Driver
- Kevlar-reinforced cone with weather treatment, 50 mm (2 in) voice coil
- HF Driver
- 25 mm (1 in) diaphragm and voice coil diameter, high temperature polymer diaphragm, patented design, fluid-cooling
- HF Driver Protection
- Minimum audibility SonicGuard? HF overload protection
- Enclosure
- ABS with Glass enclosure, heavily braced
- Attachment
- Two M10 (fine-thread) points for included U-bracket. M6 secondary safety attachment point on back panel.
- Grille
- Corrosion-resistant zinc-rich extra-thick powder coated steel grille, 3- layer assembly with foam and woven poly mesh backing
- Input Connection
- CE-compliant covered barrier strip terminals. Barrier terminals accept up to 9 mm outside 4 mm inside open-lug (#6, #8 or #10) plus bare wire up to 2.5 mm2 (12 AWG) wire or spade lugs. Terminal compartment cover equipped with gland nut that forms water-tight seal with round-jacketed cables with outside diameters between 4.0 mm (0.16) and 9.0 mm (0.36)
- Environmental
- IP56 per IEC529, with a minimum 5° downward aiming angle. Exceeds Mil Spec 810 for humidity, salt spray, temperature & UV, and ASTM G85 for acid-air/salt-spray (336 hrs).
- Included Accessories
- U-bracket, matches loudspeaker color (gray or black), zinc-rich extra thick powder coated, steel
- Suspension Attachment
- Two M10 (fine-thread) points for included U-bracket. M6 secondary safety attachment point on back panel.
Dimensions
- Dimensions
- 300 x 300 x 305 mm (11.8 x 11.8 x 12.0), cabinet 331 mm (13.0 in) including gland nut 359 mm (14.2 in) including bracket extending to back
- Net Weight (each)
- 9.8 kg (21.5 lb), 11.6 kg (25.5 lb) with U-bracket
- Shipping Weight
- 14.1 kg (31.0 lb)
