JBL Bar 5.1

General Specifications

Total Maximum Power

510W

Max SPL

104dB

Frequency Response

35Hz to 20KHz

Soundbar Weight

3.9kg 8.6 lbs

Subwoofer Weight

13 Kg 28.7 lbs

Surround Speaker Weight:

0.6kg 1.3 lbs

Dimensions

Subwoofer Transducer Size

10

Soundbar Transducer Size

6 x 2.25 racetrack drivers, 3 x 1.25 tweeter

Soundbar Dimensions (W x H x D)

1148 x 58 x 93 (mm) 45 x 2.3 x 3.7

Subwoofer Dimensions (W x H x D)

305 x 440 x 305 (mm) 16 x 12 x 12

Surround Speaker Dimensions (W x H x D)

165 x 59 x 93 (mm) 6.5 x 2.3 x 3.7

Control and Connection Specifications

Audio inputs

1 Analog, 1 Optical, Bluetooth

Antenna Input

HDMI Video Inputs

3

HDMI Video Output (with Audio Return Channel)

1

HDMI HDCP Version

2.2
