JBL BassPro 12

General Specifications

Driver Complement

12 (300mm) Subwoofer

Amplifier Power

150Wrms, 450W max

Frequency Response

30Hz – 200Hz

Fuse

25A

Maximum Current Draw

20 A

Quiescent Current Draw

<0.9A

Input Sensitivity

0.065 V – 2V Low-Level Input; 0.35 V – 10V High-Level Input

Crossover Frequency

40 Hz – 200 Hz

Crossover Slope

12 dB/octave

Bass Boost

0dB to + 12dB @ 45 Hz

Dimensions

Dimensions (W x H x D)

22-1/2 x 14-5/8 x 9-3/16D1/12-1/6D2 (570mm x 371mm x 232mm(D1)/305mm(D2)

Weight

34.30 lb (15.56kg)
