100W Continuous Program (2 hrs) ; 50 W (200W peak), Continuous Pink Noise (2 hrs) ; 40 W (160W peak) Continuous Pink Noise (100 hrs)
Maximum Input Voltage
17.2 V RMS (2 hrs), 34.4 V peak
Maximum SPL
103 dB ave. Continuous Pink Noise (109 dB peak)
Sensitivity
86 dB, 1W/1m (ave. 100 Hz – 10 kHz)
Coverage Angle
100° x 100°
Directivity Factor (Q)
5.8 (averaged 1kHz – 16kHz)
Directivity Index (DI)
7.2 dB (averaged 1kHz – 16kHz)
Nominal Impedance
8 ohms (in Thru mode)
Crossover Type
2nd order low-pass, 2nd order high-pass
Recommended Protective High-Pass
70 Hz high-pass (24 dB/oct)
Low Frequency Driver
76 mm (3.0 in), woven-fiberglass cone with pure butyl rubber surround with Weather-Edge frame protection, high-temp Kapton? voice coil former, high-temp voice coil wire, optimized cone geometry, linear suspension spider, and FEA optimized motor structure.
High Frequency Driver
13 mm (0.5 in) PEI diaphragm, low-viscosity ferro-magnetic fluid, and lightweight Kapton? voice coil former.
Included Accessories
InvisiBall? wall-mounting system, 4 mm x 80 mm hex key
