70 V = 60 W, 30 W, 15 W & 7.5 W ; 100 V = 60 W, 30 W, 15 W
Drivers
Drivers 200 mm (8 in) with paper cone, SBR surround ; HF
LF = LF
Safety Agency Rating
Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.
Environmental
IP rating = IP33 per EN/IEC 60529. Operating temperature = 0° C to 45 °C.
Optional Accessories
JBL-MTC-418BG black (RAL9004) round grille ; JBL-MTC-418SG white (RAL9003) square grille ; JBL-MTC-447NC new construction bracket ; JBL-MTC-447MR mud-ring construction bracket ; JBL-MTC-48TRX4 tile rail for 4′ x 4′ ceiling tiles
Color
Stock grille is White (RAL9003), paintable
Dimensions
Ceiling Cutout Size
282 mm (11.1 in)
Dimensions
283 mm (11.3 in) H x 315 mm (12.6 in) dia. ; 271 mm (10.8 in) from bottom of ceiling tile to top of backcan
