22.5 W (90 W Peak), Cont. Pink Noise (2 hrs.) ; 15 W (60 W Peak) Cont. Pink Noise Power (100 hrs.)
Sensitivity
86 dB
Coverage Angle
160° conical
Maximum SPL (1m)
99.5 dB Cont. pink noise (105.5 dB peak)
Nominal Impedance
16 ohms
Transformer Taps
70 V = 12 W, 6 W & 3 W ; 100 V = 12 W, 6 W
Drivers
60 mm (2.5 in) Full Range driver with paper cone, Rubber surround, CCAW coil
Safety Agency Rating
Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.
Environmental
Environmental 0° C to 45 °C.
IP rating = IP33 per EN/IEC 60529. Operating temperature
Optional Accessories
JBL-MTC-442BG black (RAL9004) round grille ; JBL-MTC-442SG white (RAL9003) square grille ; JBL-MTC-442NC new construction bracket ; JBL-MTC-442MR mud-ring construction bracket ; JBL-MTC-48TRX4 tile rail for 4′ x 4′ ceiling tiles
Color
Stock grille is white (RAL9003), paintable.
Dimensions
Dimensions
138 mm (5.4 in) H x 131 mm (5.2 in) dia. ; 129 mm (5.1 in) from bottom of ceiling tile to top of backcan
