General Specifications
- Frequency Range (-10dB)
- 74 Hz – 20 kHz
- Frequency Response (+/-3 dB)
- 91 Hz – 18 kHz
- Power Rating
- 80W Continuous Program (2 hrs) ; 40W (160W peak) Continous Pink Noise (2 hrs) ; 20W (80W peak) Continuous Pink Noise (100 hrs)
- Sensitivity
- 84 dB (80 Hz – 20 kHz) half-space (mounted on a wall)
- Maximum SPL
- 106 dB peak (100 dB continuous, 2 hr) at 1m
- Coverage Angle
- 120°H x 120°V
- Directivity Factor (Q)
- 7.5
- Directivity Index (DI)
- 8.8 dB
- Nominal Impedance
- 8Ω (at 8Ω tap setting)
- Transformer Taps
- 70V = 15 W, 7.5 W, 3.8 W, 1.9W ; 100V = 15 W, 7.5W, 3.8W
- Driver
- 75mm (3 in) full-range driver, polypropylene cone ; 20 mm (0.8 in) voice coil on Kapton? voice coil former
- Terminals
- 4-pin Euroblock connector for bare wire, accepts 24 to 14 AWG gauge (0.25 to 2.5 sq. mm)
- Enclosure Material
- Polycarbonate + ABS, UL94V-0 flammability rated
- Included Accessories
- Wall-mount slide-on bracket (speaker and wall sides), 4-pin Euroblock plug, protective terminal cover for outdoor use.
Dimensions
- Dimensions
- 248mm wide x 230mm high x 100mm deep (9.8 x 9.1 x 3.9 in)
- Net Weight
- 1.9 kg (4.2 lbs)
