JBL Small Commercial Space Sound Bundle (White)

General Specifications

Frequency Range (-10 dB)

61Hz – 20kHz

Power Capacity

75W (300W Peak) Cont. Pink Noise (2 hrs) ; 50W (200W Peak) Cont. Pink Noise (100 hrs)

Sensitivity (1m/1W)

89dB

Coverage Angle

120° conical

Maximum SPL (1m)

108 dB continuous pink noise (114 dB peak)

Nominal Impedance

8Ω

Transformer Taps

70 V = 30 W, 15 W, 7.5 W & 3.8 W ; 100 V = 30 W, 15 W, 7.5 W

Drivers

LF = 165 mm (6.5 in) with paper cone, SBR surround. ; HF = 20 mm (0.75 in) soft dome

Safety Agency Rating

Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.

Environmental

IP rating = IP33 per EN/IEC 60529. Operating temperature = 0° C to 45 °C.

Optional Accessories

JBL-MTC-416BG black (RAL9004) round grille ; JBL-MTC-416SG white (RAL9003) square grille ; JBL-MTC-416WG weather grille ; JBL-MTC-426NC new construction bracket ; JBL-MTC-426MR mud-ring construction bracket ; JBL-MTC-48TRX4 tile rail for 4′ x 4′ ceiling tiles

Color

Stock grille is White (RAL9003), paintable

Dimensions

Ceiling Cutout Size

223 mm (8.8 in)

Dimensions

233 mm (9.3 in) H x 261 mm (10.4 in) dia. ; 222 mm (8.9 in) from bottom of ceiling tile to top of backcan

Net Weight (ea)

3.75 kg (8.27 lbs)

Shipping Weight (pair)

12.64 kg (27.87 lbs)
