JBL STAGE GT 50011 Amplifier

General Specifications

Max Power

1220W peak

Power Output

500Wrms x1 @2ohms

Power Output

300Wrms x1 @4ohms

Frequency Response

10Hz – 320Hz±1dB

THD+N@ROP:1%

Input Sensitivity LOW

Input Sensitivity LOW 1V – 25V

0.2V – 5V, HIGH

Bass EQ Level

0dB to 12dB

Bass EQ Width

Narrow – Wide

Bass EQ Freq

30Hz – 100Hz

Phase Control

0°- 180° Variable

Low Pass Filter 32Hz – 320Hz

Protection

DCP, OVP, UVP, OCP, OTP

Operating Voltage

9V – 16V

Fuse Rating

30A x 2
