General Specifications
- Coverage Pattern (Nominal)
- 50° x 90°
- Frequency Range Hz (-10 dB)
- 60 – 20,000
- Frequency Response Hz (±3 dB)
- 70 – 20,000
- Maximum SPL (peak dB)
- 133
- Nominal Impedance (ohms)
- 8
- Power Rating (W, Continuous)
- 800
- Power Rating (W, Peak)
- 3200
- Sensitivity (dB SPL 1w/1m)
- 98
Dimensions
- Depth (in)
- 12.75
- Depth (mm)
- 324
- Height (in)
- 24.75
- Height (mm)
- 629
- Weight (kg)
- 21
- Weight (lbs)
- 46
- Width (in)
- 17
- Width (mm)
- 432
Design
- Enclosure
- Symmetrical stage monitor, 15/18 mm, plywood
- Finish
- Black DuraFlex? finish
- Grille
- Powder coated, black, 16-gauge perforated steel with with acoustically transparent foam
Features
- JBL professional tunings and presents available
- Yes
