General Specifications
- High Frequency Transducer
- 1 (25mm) Aluminum dome with Acoustic Lens
- Low Frequency Transducer
- 6.5 (165mm) Polycellulose cone woofer
- Recommended Amplifier Power (Full Range)
- 20-100W RMS
- Frequency Response
- 50Hz-25kHz (-6dB on-axis)
- Sensitivity (2.83V@1m)
- 87dB
- Nominal Impedance
- 8ohm
- Crossover Frequency
- 3000Hz
- Inputs
- Nickel-plated spring-loaded connectors
- Grille Dimensions
Grille Dimensions 9.2in (233mm)
- Dia
- Cutout Dimensions
Cutout Dimensions 8in (203mm)
- Dia
- Mounting Depth
- 3.9in (100mm)
- Product Weight (Kg)
- 1.9Kg
- Shipping Carton Dimensions
- L 11in (280mm) x W 11in (280mm) x H 5.4in (136mm)
- Shipping Carton Weight
- 5.6lbs (2.54Kg)
