General Specifications
- High Frequency Transducer
- 1 (25mm) Compression Driver with High-Definition Imaging (HDI?) waveguide
- Low Frequency Transducer
- 8 (203mm) Polyplas? woofer
- Nominal Impedance
- 6-Ohm
- Sensitivity (2.83V@1m)
- 93dB
- Power Handling
- 60W RMS (250W Dynamic)
- Recommended Amplifier Power
- 50 – 80W
- Frequency Response
- 43Hz – 20kHz
- Crossover Frequency
- 2.5kHz
- Grille Dimensions (HxW)
- 9.9 x 13.7 (251mm x 349mm)
- Cutout Dimensions (HxW)
- 8.7 x 12.5 (221mm x 318mm)
- Mounting Depth
- 3.74in (95mm)
