General Specifications
- Finish
- Black
- Type
- Floor-Standing Speakers
Audio Specifications
- Maximum Recommended Amplifier Power
- 200W
- Power Handling (Recommended)
- 100W
- Power Handling (Peak)
- 400W
- Nominal Impedance
- 8 ohms
- Crossover Frequencies
- 700Hz, 5000Hz, 20kHz
- Frequency Response
- 30Hz-40kHz
- Sensitivity
- (2.83V@1m) 91dB
Dimensions
- Height (mm)
- 990
- Height (in)
- 39
- Depth (in)
- 14-3/4
- Weight (lb)
- 54
- Weight (kg)
- 24.4
- Depth (mm)
- 370
- Width (mm)
- 222
- Width (in)
- 8-3/4
Speaker Specifications
- High-Frequncy Transducer
- 1 Pure-Titanium Dome with Cast-Aluminum Chassis in JBL EOS Waveguide
- Ultra High Frequency Transducer
- 19mm (3/4) Mylar Dome with Cast-Aluminum Chassis
- Low-Frequency Transducer
- Dual 6 PolyPlas Cones with Rubber Surrounds and Cast-Aluminum Chassis; HeatScape Motor Structures; Symetrical Field Geometry (SFG)
- Midrange Transducer
- 4 PolyPlas Cone with Rubber Surround and Cast-Aluminum Chassis; HeatScape Motor Structure
