CDi 1000

General Specifications

Input Impedance (K Ohms, balanced)

20

Input Impedance (K Ohms, unbalanced)

10

Rated Power Output (W, stereo, per channel at 4Ω)

500

Rated Power Output (W, stereo, per channel at 8Ω)

275

Sensitivity (V, for full rated power at 4Ω)

1.3

Signal to Noise Ratio (dB, below rated 1kHz power at 8Ω, A-weighted)

100

Total Harmonic Distortion (THD)

< 0.5%

Dimensions

Depth (in)

12.5

Depth (mm)

318.0

Height (in)

3.5

Height (mm)

89.0

Weight (kg)

10.0

Weight (lbs)

22.0

Width (in)

19.0

Width (mm)

482.6

Features

Euroblock / Phoenix inputs

Yes

Barrier Strip outputs

Yes

Forced-air cooling

Yes

LCD display

Yes

HiQnet System Architect? control software

Yes
