70 V = 15 W, 7.5 W, 3.8 W & 1.9 W ; 100 V = 15 W, 7.5 W, 3.8 W
Drivers
76 mm (3 in) full range driver with paper cone and SBR surround
Safety Agency Rating
EN 54-24:2008 certified Type A. Designed in accordance with BS 5839-8 and EN 50849. Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.
Environmental
IP rating = IP33 per EN/IEC 60529. Operating temperature = 0° C to 45 °C.
Optional Accessories
JBL-MTC-414BG black (RAL9004) round grille ; JBL-MTC-414SG white (RAL9003) square grille ; JBL-MTC-414WG white (RAL9003) weather grille ; JBL-MTC-424NC new construction bracket ; JBL-MTC-424MR mud-ring construction bracket ; JBL-MTC-48TRX4 tile rail for 4′ x 4′ ceiling tiles
Color
Stock grille is White (RAL9003), paintable
Dimensions
Ceiling Cutout Size
168 mm (6.6 in)
Dimensions
163 mm (6.5 in) H x 203 mm (8.1 in) dia. ; 154 mm (6.2 in) from bottom of ceiling tile to top of gland nut.
