High-efficiency 200 mm (8 inch) dual-cone driver with 25 mm (1 in) diameter voice coil, Kapton coil former, and high-temperature voice coil wire.
Frequency Range (-10dB)
100 Hz – 16 kHz
Sensitivity
96 dB (2 kHz – 6 kHz)
Coverage Angle
100° conical
Maximum SPL (1m)
108 dB (low-impedance, 116 dB peak) 106 dB (top 70V/100V tap)
Impedance
8 ohms (in direct/thru setting)
Transformer Taps
10 W, 5 W, 2.5 W (plus 1.3 W @ 70V)
Recommended Protective High Pass
90 Hz high-pass (24 dB/oct) for 8Ω direct or any 70V or 100V tap setting
Power Capacity (at low-Z)
40 Watts Continuous Program Power 20 Watts Continuous Pink Noise
Input Connectors
Bare wire inside protected in touch-proof wiring compartment
Tap Selector
Rotary switch accessible from side of backcan
Materials
Steel rear enclosure, front baffle, and perforated grille
Grille Color
White
Safety Agency
Suitable for use in air handling spaces certified per UL1480A, Speakers for Commercial and Professional Use; UL2043, Standard for Fire Test for Heat and Visible Smoke Release for Discrete Products Installed in Air-Handling Spaces; NFPA90 & NFPA70; S7232/UL Listed, Signaling Speaker.
Suspension / Safety-Seismic Attachment Points
Two tabs on back baffle, plus 4 holes in corners
Power Rating
See transformer taps
Backcan
formed steel (blind-mount)
Baffle/Rim
Metal
Plenum Usage
Yes, backcan included
Dimensions
Dimensions
607 x 607 x 103 mm (23.9 x 23.9 x 4.1 in)
Net Weight
7.1 kg (15.7 lbs)
Shipping Weight
8.3kg ea; 16.5 kg per pair-pack (18.3 lbs ea; 36.4 lbs per pair-pack)
Ceiling Cutout Size
No cutout required. Speaker drops into ceiling grid
