General Specifications
- Frequency Range Hz (-10 dB)
- 31 – 220
- Frequency Response Hz (±3 dB)
- 34 – 220
- Maximum SPL (peak dB)
- 130
- Nominal Impedance (ohms)
- 8
- Power Rating (W, Continuous)
- 800
- Power Rating (W, Peak)
- 3200
- Sensitivity (dB SPL 1w/1m)
- 95
Dimensions
- Depth (in)
- 29.5
- Depth (mm)
- 749
- Height (in)
- 20
- Height (mm)
- 508
- Weight (kg)
- 37
- Weight (lbs)
- 81
- Width (in)
- 23.5
- Width (mm)
- 597
Design
- Enclosure
- Rectangular, 18 mm, 13-ply birch plywood
- Suspension / Mounting
- Optional VRX932LA-AF line array frame kit or 10mm eyebolt
- Finish
- Black DuraFlex? finish
- Grille
- Powder coated, black, 16-gauge perforated steel with with acoustically transparent foam
Features
- JBL professional tunings and presents available
- Yes
- M10 suspension points
- Yes
- Single-angle top pole-mount socket
- Yes
