General Specifications
- Frequency Range (-10dB)
- 70 Hz – 18 kHz
- Frequency Response (±3 dB)
- 100 Hz – 16 kHz
- Coverage Pattern
- 110o x 110o
- Directivity Factor (Q)
- 7.2 (1 k – 16 kHz)
- Directivity Index (DI)
- 7.9 dB (1 k – 16 kHz)
- System Power Rating
- 175 W 2 hrs. 120 W 100 hrs (IEC rated)
- Sensitivity (2.83V @ 1m)
- 92 dB (Ave. 100 Hz – 18 kHz)
- Maximum SPL (1m)
- Direct 8Ω = 114 dB (peaks of 120 dB) ; 120 W Tap = 112 dB
- Crossover Network
- 1.8 kHz, 3rd order (18 dB/oct) high-pass plus conjugate to HF, 3rd order low-pass to LF
- Nominal Impedance
- 8 ohms
- Transformer Taps
Transformer Taps 120W, 60W, 30W, 15W 100V
- 70V
- LF Driver
- Kevlar-reinforced cone with weather treatment, 38 mm (1.5 in) voice coil.
- HF Driver
- 25 mm (1 in) diaphragm and voice coil diameter
- HF Driver Protection
- Minimum audibility SonicGuard? HF overload protection
- Enclosure
- ABS with Glass enclosure
- Attachment
- Two M10 (fine-thread) points for included U-bracket. M6 secondary safety attachment point on back panel.
- Grille
- Corrosion-resistant zinc-rich extra-thick powder coated steel grille, 3-layer assembly with foam and woven poly mesh backing.
- Input Connection
- CE-compliant covered barrier strip terminals. Barrier terminals accept up to 8 mm outside 4 mm inside open-lug (#6 or #8) plus bare wire up to 2.5 mm2 (12 AWG) wire or spade lugs. Terminal compartment cover equipped with gland nut that forms water-tight seal with round- jacketed cables with outside diameters between 4.0 mm (0.16”) and 9.0 mm (0.36”).
- Environmental
- IP56 per IEC529, with a minimum 5° downward aiming angle. Exceeds Mil Spec 810 for humidity, salt spray, temperature & UV, and ASTM G85 for acid-air/salt-spray (336 hrs).
Dimensions
- Dimensions
- 259 x 259 x 255 mm (10.2 x 10.2 x 10.1 in), cabinet 288 mm (11.4 in) including gland nut 309 mm (12.2 in) including bracket extending to back
- Net Weight (each)
- 6.8 kg (15.0 lb), 7.7 kg (17.0 lb) with U-bracket
- Shipping Weight
- 8.8 kg (19.5 lb)
