120 W Continuous Program (2 hrs) ; 60 W (240 W Peak), Continuous Pink Noise (2 hrs) ; 40 W (160 W Peak) Continuous Pink Noise Power (100 hrs)
Sensitivity
85 dB
Coverage Angle
130° conical
Maximum SPL (1m)
103 dB continuous pink noise (109 dB peak)
Nominal Impedance
16 ohms
Transformer Taps
70 V = 30 W, 15 W, 7.5 W & 3.7 W ; 100 V = 30 W, 15 W, 7.5 W
LF Driver
100 mm (4 in)
HF Driver
19 mm (0.75 in)
Safety Agency Rating
Suitable for use in air handling spaces per UL1480A, UL2043, NFPA90 & NFPA70, S7232/UL Listing, Speakers for Commercial and Professional Use. Listed per CSA C22.2, no. 205 Signal Equipment. In accordance with IEC60849/ EN60849.
Environmental
Exceeds Mil Spec 810H for humidity, salt spray, temperature & UV. IP33 rating per EN/IEC 60529 against solid object and water ingress. Compliant with RoHS2 per EN/IEC63000. Operating temperature 0°C to 45°C
Optional Accessories
JBL-MTC-424BG black (RAL9004) magnetic round grille, JBL-MTC-424SG white (RAL9003) magnetic square grille, JBL-MTC-424NC new construction bracket, JBL-MTC-424MR mud-ring construction bracket
Color
Stock grille is white (RAL9003), paintable.
Dimensions
Dimensions
182 mm (7.2 in) H x 196 mm (7.7 in) dia. 173 mm (6.8 in) from bottom of ceiling tile to top of backcan (with wire exit positioned on side of backcan).
